Wilkerson M18-C4-CH00 Filter

Wilkerson M18-C4-CH00

FeaturesThis modular coalescing filter includes:High-efficiency Removal of Water, Oil Aerosols, and Solid ParticulateContaminants Down to 0.01 ppm/wt with Minimum Pressure DropModern Design and AppearanceLight WeightHigh Flow CapacityBowl GuardQuick-disconnect BowlSpecificationsFlow Capacity*1.0 Micron Coalescing53 SCFM (25 dm3/s, ANR)0.01 Micron Coalescing36 SCFM (17 dm3/s, ANR)Activated Carbon Adsorber85 SCFM (40 dm3/s, ANR)Maximum Supply PressurePlastic Bowl150 PSIG (10.3 bar)Metal Bowl with DPI150 PSIG (10.3 bar)Metal Bowl without DPI250 PSIG (17.2 bar)Operating TemperaturePlastic Bowl-13° to 125°F (-25° to 52°C)Metal Bowl-13° to 150°F (-25° to 65.5°C)Port SizeNPT / BSPP-G1/4, 3/8, 1/2Bowl Capacity1.72 ozStandard Filtration(micron)(B) 0.5, (C) 0.01, (D) 0.003 ppm wt3 **Weight0.71 lb. (0.32 kg)* Inlet pressure 91.3 PSIG (6.3 bar). Pressure drop 3 PSIG (0.2 bar).

AIR FILTER REGULATOR / PORT SIZE:1/2″
