TESCOM 44-5265-243V Regulato

TESCOM 44-5265-243V Pressure Reducing Regulator Venting 5-500 PSIG – Stainless Steel

Applications:

• Test equipment
• Calibration stands
• Production equipment

Features:

• Compact and economical design
• For gas or liquid service
• Piston sensed for high reliability and long service life
• Standard version includes 1/4″ in. NPT gauge ports
• Stainless Steel Construction
• Adjustable stop limits maximum outlet pressure

Specifications:

• Maximum Inlet Pressure: 3500 psig (241 bar)
• Outlet Pressure Range: 5-500 psig (0.35-34.5 bar)
• Design Proof Pressure: 150 percent maximum rated
• Operating Temperature: -15°F to 200°F (-26°C to 93°C)
• Maximum Operating Torque: 30 in-lbs (3.4 N•m)
• Body Material: 316 Stainless Steel
• Inlet Pressure: 5-500 psig / 0.35-34.5
• Flow Capacity Standard: Cv = 0.15
• Optional Venting: Venting
• Connections: 1/4″ in. NPT Inlet, Outlet and Gauge Ports

Media Contact Materials:

• Body: 316 Stainless Steel
• Bonnet: 316 Stainless Steel
• Piston: 316 Stainless Steel
• Seats: Vespel®
• O-Ring: Viton®
• Filter (40 micron): 316 Stainless Steel
• Remaining Parts: 316 Stainless Steel

Other:

• Cleaning: CGA 4.1 and ASTM G93
• Weight (without gauges): 2 lbs / 0.9 kg
