steimel GEAR PUMP TFL8-170 GDG

CONNECTIONS: SIMILAR TO ANSI / ASME B16.5
4“; 150 lb / sq. In.
but with je 8 x M16

operating manual: DBA-ZP02, DBA-PA-ATEX-01 – casing parts : GG-25

shafts :16MnCrS5, hardened – helical toothed, flange-polished

bearing: multilayer MD

shaft sealing: mechanical seal M3/40+V+L

temperature control : IPB014 – jacket-resistance-thermometer TR 10-H

with connection head

without Transmitter (area -50 bis +250°C)

II 2 GD EEx Ia IIC T +250°C
