FIRE & GAS DETECTION SYSTEM
INCLUDING CONTROL PANEL & SENSOR & SMOKE DETECTOR & ACCESSORY EQUIPMENT NUV /IR FLAME DETECTOR SHARPEYE TM
Spectrex 40/40LB-111SC Features
UV/IR Dual-Sensor
Solar Blind
Automatic Built-In-Test (BIT) and Manual- to assure continued reliable operation (in 40/40LB only)
Heated window – for operation in harsh weather conditions (snow, ice, condensation)
Multiple output options for maximum flexibility and compatibility
-Relays (3) for Alarm, Fault and Auxiliary
-0-20mA (stepped)
-HART Protocol for maintenance and asset management
-RS-485, Modbus Compatible
High Reliability – MTBF – minimum 150,000 hours
Approved to Safety Integrity Level 2 (SIL2 – TUV) – Model 40/40LB only
5-Year Warranty
User Programmable via HART or RS-485
Hazardous area zones:
-Zones 1 & 2 with IIC gas group vapors present
-Zones 21 & 22 with IIIC dust type present
Ex approved to:
-ATEX & IECEx
-FM/FMC/CSA
-TR CU (EAC)
3rd party performance approved
-EN54-10 (VdS)
-FM3260
Marine Approval
-WITH “Wheelmark” approval (DNV)
Reliability
-IEC61508 – SIL2 (TUV) – model 40/40LB only
