Rosemount Analytical 396PVP TUpH pH/ORP Sensors

The Rosemount Analytical Model 396P / 396PVP TUpH pH/ORP Sensors are SMART enabled (-01). SMART preamplifier option is the standard option with the 396P. In addition, the 396P features an optional integral hermetically sealed preamplifier with 25 ft cable lengths. The 396P is housed in a molded reinforced polypropylene body with 1 in. MNPT threads suitable for insertion, submersion or flow through installation. The sensor includes a general purpose pH electrode or a platinum ORP electrode, a reference junction and a solution ground. The 396P comes standard with a recessed electrode; an optional slotted tip is also available. Automatic temperature compensation, Pt 100 or 3K Balco, is standard with the 396P.

The 396PVP Sensor has similar features to the 396P. The 396PVP is now SMART enabled (-70). SMART is the standard preamplifier option. The 396PVP is offered with the Variopol (VP) connector, that uses a mating VP cable (purchased separately). A remote preamplifier must be used if non-SMART option is selected.

Features

• SMART enabled
• Silcore technology provides increased sensor life
• Quick cable to sensor release
• Minimal sensor maintenance
• Maximum sensor life
• Field proven Accuglass
• Advanced sensor diagnostics
