Rosemount 225 Conductivity Sensor

The Rosemount Analytical Model 225 non-contacting toroidal (inductive) conductivity sensor is intended for pharmaceutical and food and beverage applications where a sanitary design is required. Depending on the analyzer used, the Model 225 sensor can measure conductivity as low as15 uS/cm and as high as 2,000,000 uS/cm.

The sensor is available in glass-filled and unfilled PEEK and in unfilled Tefzel®. The unfilled PEEK sensor is available in two options: one meeting 3A sanitary and FDA food contact standards and the other meeting USP Class VI requirements.

The maximum temperature depends on the sensor materials. The limit for glass-filled PEEK and unfilled Tefzel is 230°F (110°C); for unfilled PEEK the limit is 266°F (130°C). The pressure limit is 200 psig (1480 kPa abs).

Rosemount 225 Features

• Easy in-line installation
• 2 inch tri-clamp fitting
• 3A standards option
• Max pressure: 200 psi
• Cell constant (nominal): 2.7/cm
• Minimum conductivity: 200 uS/cm
• Maximum conductivity: 2 S/cm
