Part number: XNX-AMSV-RNNNN
HART over 4-20mA output, ATEX/IEC approved, 5 x M25, 316 SS, alarm and fault relay outputs, configured for mV sensors
توان تجهیز دنا
Power Consumption
|
Configuration
|
Max Power
|
Inrush
|
|
XNX EC
|
6.2 w
|
<1A, <10ms@24VDC
|
|
XNX mV
|
6.5 w
|
<750mA <2ms@24VDC
|
|
XNX IR (Optima)
|
9.7w
|
<1A, <10ms@24VDC
|
|
XNX IR (Excel)
|
13.2w
|
<1A, <10ms@24VDC
|
Signal
| Standard | HART over 3-wire 4-20 mA (sink, source, or isolated) | |
| Optional | Modbus over RS-485 | |
| 20 mA | HART over 3-wire 4-20mA (sink, source, or isolated) compliant with NAMUR NE43 | |
| Cable Ports | 5 – (2 right, 2 left, 1 bottom) Available in 3/4″ NPT, or M25 | ||
| Unpowered battery life | (Real Time Clock) 3 years at rated storage temperature | ||
| Material | Marine grade aluminum alloy or SS316. 5-coat painted finish. | ||
| Dimensions | 159 x 197 x 113.8 mm / 6.138 x 7.75 x 4.48 inches | ||
| Weight | 2.27 kg (5 lb) Aluminum 5 kg (11 lb) Stainless |
||
| XNX® Enclosure | Integral Mounting Lugs for Wall- or Optional Pipe-Mount, Optional Wall/ Ceiling Bracket | ||
| User Interface | |||
| Standard | Custom Backlit LCD, magnetic wand operation of local user interface | ||
| Optional | HART Handheld with IS Port | ||
| Temperature* | Transmitter: -40°C to +65°C (-40°F to +149°F) | ||
| MPD**-CB1: -40°C to +65°C (-40°F to +149°F) | |||
| MPD**-I**: -20°C to +50°C (-4°F to +122°F | |||
| Humidity | 0 to 99% RH non-condensing | ||
| Pressure | 80 kPa to 120 kPa | ||
| Air Speed | 0-6 m/sec | ||
