GO™ Switch (TopWorx™) 73-1356X-JAM Model 73

GO™ Switch (TopWorx™) 73-1356X-JAM Model 73 SPDT Ag/Pd Dry Contact, 4A @ 120VAC/3A @ 24VDC, 2A @ 240 VAC/1.25A @ 48VDC, 2.5mm (0.1in) End Sensor Ferrous, Bottom Out Aluminum M20 Connector.

73-1356X-JAM FEATURES

• Single Pole Double Throw (SPDT) 2A/240VAC, 4A/120VAC, 3A/24VDC
• AC/DC, NO/NC Wiring Flexibility
• -50° C to 105° C (-58° F to +221° F) operating temperature
• 2.5 mm (0.100 in) Sensing Distance (Ferrous metal)
• Dry Contact
• Intrinsically Safe
• End sensing
• Palladium Silver Contacts
• Stainless Steel 316L Housings

OPTIONS

• High Temperature: -50° C to +204° C (-58° F to +400° F)
• Pressure Rating: 2,000, 5,000, 10,000 PSI, (140, 345, 690 bars)
• Lead Wires or Cables
• SubSea Connectors
• Hermetic Seal
• Quick Disconnects – Micro or Mini
• 5/8″ or M18 metric thread
• Global Hazardous Area Approvals
