GO™ Switch (TopWorx™) 72-16567-DBD Model 72

GO™ Switch (TopWorx™) Model 72, cULus General Purpose, 2000psi 316L SS Enclosure, 3/8-24UNF x 3-15/16in Overall Length 1/2-14FPT Conduit, SPDT Ag/Pd Dry Contact, 4A @ 120VAC/3A @ 24VDC, 2A @ 240 VAC/1.25A @ 48VDC, 1mm (0.04in) End Sensor Ferrous, Bottom Out 4-pin Micro Connector.

72-16567-DBD FEATURES

• Single Pole Double Throw (SPDT) 2A/240VAC, 4A/120VAC, 3A/24VDC
• AC/DC, NO/NC Wiring Flexibility
• -50° C to 105° C (-58° F to +221° F) operating temperature
• 1 mm (0.040 in) Sensing Distance (Ferrous metal)
• Dry Contact
• Intrinsically Safe
• End sensing
• Palladium Silver Contacts
• Stainless Steel 316L Housings

OPTIONS

• High Temperature: -50° C to +204° C (-58° F to +400° F)
• Lead Wires or Cables
• Quick Disconnects – Micro
• 3/8″ or M12 metric thread
• ATEX/IECEx Hazardous area approvals
