E+H Liquipoint T FTW31 Level Switch

Liquipoint T FTW31 Features

• Detection of up to five point levels
• No calibration required
• 0.1 to 4m (3.9 to 157″) sensor length
• Threaded process connections
• 10 µS/cm min. conductivity of medium
• No moving parts in the tank
• -40 to 100°C (-40 to 212°F) temperature range
• -1 to 10 bar (-14.5 to 145 psi) pressure range
• International explosion protection certificates

The E+H Liquipoint T FTW31 level switch is used for point level measurement in conductive liquids (from 10 µS/cm). Depending on the number of measuring points (up to 5 rods or ropes), measuring tasks such as overfill protection, dry running protection, two-point control of pumps or multiple point detection can be implemented.
