E+H Cerabar PMP51 Pressure Transmitter

The E+H Cerabar PMP51 Pressure Transmitter features a metal membrane and is typically used in process and hygiene applications for pressure, level, volume or mass measurement in liquids or gases. PMP51 is designed for high pressure applications up to 400bar. Quick Setup with adjustable measuring range allows simple commissioning, reduces costs and saves time. SIL2 according to IEC 61508 and IEC 61511.

Cerabar PMP51 Features

• Welded metal sensor
• Aluminum or stainless steel (316L) housing
• -15/0 up to 6,000psi (-1/0 up to 400bar) measuring range
• -40 to 266°F (-40 to 130°C) process temp
• ±0.15% accuracy
• Flush mounted process connections
• Threads, flanges or hygienic process connections
• Up to SIL2, certified to IEC 61508/IEC 61511
• Easy replacement of display or electronics
• Seamless and independent system integration
