Part number: 58000-300APO
Origin: UK
توان تجهیز دنا
دتکتور مونوکسید کربن DISCOVERY حاوی یک سنسور مونوکسیدکربن الکتروشیمیایی با عمر طولانی است که در برابر سطوح پایین بخارات و محصولات خانگی مقاوم است.
| Mechanical |
| Colour: White |
| Weight: 105g |
| Materials housing: Polycarbonate |
| Materials terminals: Nickel plated stainless steel |
| Product length:42mm |
| Product diameter:100mm |
| Detection principle: Ambient carbon monoxide level. |
| Product length: 1.65in |
| Product diameter: 3.94in |
| Performance |
| Chamber type: Chevron |
| Analogue value nominal: 25 |
| Analogue value (- tolerance): 2 |
| Analogue value (+ tolerance): 2 |
| Analogue value: 25 +2/-2 |
| Alarm level analogue value: 55 |
| Electrical |
| Protocol voltage: 5 to 9V peak to peak |
| Protocol voltage (max): 9V |
| Protocol voltage (min): 5V |
| Power-up surge current: 1mA |
| Maximum power-up time: 10 seconds |
| Status indicator – Alarm: Red |
| Quiescent current: 500μA |
| Quiescent current tested at: 24V dc |
| Terminal functions L2: +L2 Loop in & out positive |
| Terminal functions L1 in: -L1 in Loop in & out, double terminal |
| Terminal functions +R: +R Remote indicator positive connection |
| Terminal functions -R: -R Remote indicator negative connection |
| Polarity: L1 & L2 are polarity sensitive |
